Introduction

A Blank recipe is a small JSON file that describes a 3D world. It lists the parts of the world, their shapes and materials, and how they move. People and AI agents write recipes. The Blank engine reads a recipe, builds the 3D model, renders it and can export it as a standard 3D file.

This page is the open specification. Anyone may read, write and generate recipes, and build tools that use them. See the license.

A whole recipe

{
  "version": 1,
  "revision": 0,
  "name": "A small lantern",
  "budget": {"triangles": 2000, "nodes": 16, "lights": 1, "particles": 24},
  "materials": {"stone": {"color": "#AFC3C6", "roughness": 0.85},
                "magic": {"color": "#38E0C3", "emission": 0.9}},
  "rhythms": {"glow": {"period": 5, "direction": [0, 0, 1], "wavelength": 30}},
  "parts": [
    {"id": "base", "material": "stone", "position": [0, 0.2, 0],
     "geometry": {"kind": "cone", "radius": 0.4, "top_radius": 0.3, "height": 0.4, "segments": 7}},
    {"id": "heart", "parent": "base", "material": "magic", "position": [0, 0.8, 0],
     "geometry": {"kind": "ico_sphere", "radius": 0.15, "subdivisions": 1},
     "animation": {"rhythm": "glow", "lift": 0.06, "pulse": 0.05},
     "light": {"color": [0.25, 1, 0.8], "intensity": 0.9, "range": 3.5}}
  ]
}
